WildTrail

WildTrail WT3M 3* XHP50.2/SST40 6800lm EDC 21700 Flood Flashlight

Write a review
| Ask a question

Regular price $46.90 USD
Regular price $59.95 USD Sale price $46.90 USD
Color
Design



Specification:

Brand WildTrail
Model WT3M
LED  XHP50.2, SST40
Output 6800lm(XHP50.2), 5500lm(SST40)
Intensity SST40: up to 44.000 cd (ANSI throw up to 430 m)
XHP50.2: up to 22.500 cd (ANSI throw up to 300 m)

Battery

1x 21700  (Battery length must be within 70mm and 72.5mm) not include

Driver

FET driver with temperature control (see calibration in the UI chart). Reverse polarity protection, low parasitic drain (< 120 µA)

Charging

USB-C port (input up to 5V 2A)

Body

Aluminum with hard black anodized or clear coated aluminum alloy

Button

Tactile electronic side switch with back-lit boot

Ingress rating

Equivalent to IPX-8, do not immerse in liquids

Size

Length: 103.5mm / Head: 39.6mm / Tube: 28.5mm / Tailcap: 29.2mm

Impact resistance

2 m

Weight

128 grams without battery



Features:

Emitter: 3x 3V Luminus SST40 5.000K (DC) 70CRI, mounted on copper DTP MCPCB

3x 3V Cree XHP50.2 6.000K (1D) 70CRI, mounted on copper DTP MCPCB

Luminous Flux: SST40: up to 5.500 lm

XHP50.2: up to 6.800 lm

Intensity: SST40: up to 44.000 cd (ANSI throw up to 430 m)

XHP50.2: up to 22.500 cd (ANSI throw up to 300 m)

Firmware: Open source software called Andúril, distributed under the terms of the GPL v3.

The source code is available from http://tiny.cc/TKAnduril

Firmware revision: 2019-12-03

Battery: 1x 21700 rechargeable lithium-ion battery

Battery length must be within 70mm and 72.5mm

Protected cells may not fit. Battery is not included.

Driver: FET driver with temperature control (see calibration in the UI chart)

Reverse polarity protection, low parasitic drain (< 120 µA)

Charging: USB-C port (input up to 5V 2A)

Reflector: Orange Peel (OP) aluminum alloy reflector

Lens: Glass with doubleside anti-reflective coating

Body: Aluminum with hard black anodized or clear coated aluminum alloy

Button: Tactile electronic side switch with back-lit boot

Ingress rating: Equivalent to IPX-8, do not immerse in liquids

Impact resistance: 2 m

Weight: 128 grams without battery





Package included:

1 x WildTrail WT3M Flashlight

1 x Manual
